Shear Beam Load Cell

Name: Shear Beam Load Cell
Brand: V. R. Enterprise

Get a Price/Quote

MOQ : 10 Units

Shear Beam Load Cell Specification

Operate Method
Automatic

Material
Metal

Color
Silver

Application
Industrial

Accuracy
100 %

Shear Beam Load Cell Trade Information

Minimum Order Quantity
10 Units

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Shear Beam Load Cell

Shear Beam Load Cell is a high-quality automatic-operated product designed for industrial applications. Its silver color and durable metal material make it a reliable choice for various industrial weighing processes. With an outstanding accuracy of 100%, this load cell ensures precise measurements, providing efficiency and accuracy in your operations.

Technical SPECIFICATIONS

	Shear Beam Load Cell
Precision	C2/C3
Composition Error	0.03/0.02
Rated Output (mv/v)	3.0 0.2
Non-Linearity (%FS)	0.025
Hysteresis (%FS)	0.02
Repeatability (%FS)	0.02/0.01
Creep (%F.S /30min)	0.03/0.02
Zero Balance (%FS)	1.0
Input Resistance ()	400 10
Output Resistance ()	350 2
Insulation Resistance (M)	20000(50VDC)
Excitation Voltage (V)	5 ~15 (DC)
Compensated Temp. Range (C)	-10~+ 50
Use Temp. Range (C)	-20~+60
Temp. Effect On Zero (%FS/10C)	0.02
Temp. Effect On Span (%FS/10C)	0.02
Safe Overload (%FS)	150
Ultimate Overload (%FS)	250
Defend Grade	IP67
Cable	5 mtr
